525 Gallon Water Tank Trailer

Call 888-512-3359 or contact us online for details.

DOT SPEC AG SPEC
Weight: Dry: 1,000 lbs
Loaded: 5,373 lbs
Weight: Dry: 1,000 lbs
Loaded: 5,373 lbs
Unit Dimensions: 145” L X 80” H X 84” W Unit Dimensions: 145” L X 80” H X 84” W
Frame Construction: 5” Channel Iron Frame Construction: 5” Channel Iron

Get a Quote

DOT SPEC AG SPEC
DOT Compliant: Yes No
Capacity: 525 Gallon 525 Gallon
Weight: Dry: 1,000 lbs
Loaded: 5,373 lbs
Dry: 1,000 lbs
Loaded: 5,373 lbs
Unit Dimensions: 145” L X 80” H X 84” W 145” L X 80” H X 84” W
Frame Construction: 5” Channel Iron 5” Channel Iron
Axle(s): 1- 7,000 lbs electric brake (total capacity)
slipper leaf-spring
1- 6,000 lbs (total capacity)
slipper leaf-spring
Tires: ST235/80R16 (10PLY)
8X6.5 BC 3500 MAX LOAD
11L-15 (8-PLY) Implement
Tires 2540 MAX LOAD
Brakes: Yes No
Fenders: Yes No
Lights: Yes No
Hitch Compatibility: (Height Adjustable )
2 5/16″ Ball Coupler
20,000 # RATING
(Height Adjustable )
2 5/16″ Ball Coupler
2″ Ball Coupler, or Clevis
Tank Type: Horizontal Leg Tank
Rotationally Molded
Horizontal Leg Tank
Rotationally Molded
Tank Color: Black Black
Water Distribution 2″: Single adjustable angle
stainless steel nozzle
98 GPM @ 20 PSI
Single adjustable angle
stainless steel nozzle
98 GPM @ 20 PSI
Motor: 5.5 HP Honda GX160 Series 5.5 HP Honda GX160 Series
2″ Pump: 2″ Self Priming Centrifugal
Polypropylene Pump, 190 gal. p/min
open discharge (BANJO 200PH5)
2″ Self Priming Centrifugal
Polypropylene Pump, 190 gal. p/min
open discharge (BANJO 200PH5)
3″ Pump:
Valves Fittings: 2″ FULL PORT BANJO
VITON FLANGE
FITTINGS SCHEDULE 80
2″ FULL PORT BANJO
VITON FLANGE
FITTINGS SCHEDULE 80
Spray Hose: Optional includes
Fire Hose Nozzle
Optional includes
Fire Hose Nozzle
Quick Fill System: STANDARD 2″ FILL &
GARDEN HOSE FILL
WITH FLOAT
STANDARD 2″ FILL &
GARDEN HOSE FILL
WITH FLOAT
Filling Platform: STANDARD STANDARD
Safety Chain Rating: 15,000 lb break strength 15,000 lb break strength
Jack Rating: BULLDOG 2,000 lb 15″ TRAVEL BULLDOG 2,000 lb 15″ TRAVEL
Frame Warranty: 5 years 5 years



500 Gallon Water Tank Trailer

The smallest trailer in our range, this 500 gallon water tank trailer model has the dual benefit of holding a substantial amount of water, while still being easy enough to maneuver around. A popular choice, this model’s configuration is perfect for filling up water troughs, spraying down your equipment, and watering your arena footing. So handy and simple to use, you’ll wonder how you ever managed life on your ranch without it.

Easy to tow, our motor-powered water systems are supported by a channel iron frame that we’ve carefully designed ourselves. With various options for water delivery, water pressure, and control settings our systems can be used in anything from arena moisture management and dust abatement to fire protection and watering livestock, to name just a few.

Each of our water trailers is powered by a Honda motor with a self-priming centrifugal polypropylene pump and plumbing kit with a 2” or 3” nozzle dispersing 98 gallons per minute at 20 psi for maximum fire control. Best of all, our systems feature an optional fire hose nozzle for rapid water dispersion.

Did you know we ship our water systems throughout the US? We’ll ship your trailer from one of our three locations that are closest to you at a reasonable cost. Call us at 888-512-3359 or contact us online to learn more about our popular Kiser Water Trailers.
